Diamond LED Garage Lighting Kit - Compact with Border (Non-Dimmable)

Diamond LED Garage Lighting Kit - Compact with Border (Non-Dimmable)

$349.99 USD
$349.99 USD
Sale Sold out
Shipping calculated at checkout.

Free shipping (lower 48) · Ships in 1–3 business days from DFW

Package

The Diamond look in a tighter footprint. Same rhombus lattice, same border trim, sized for single bays, studios, and barbershop stations where the full-width Diamond won't fit. If you want the ceiling nobody else has, in a room everybody actually has, this is the one.

Build Quality

  • Aluminum frames throughout, including the border trim. No plastic, no sag, no warping.
  • Copper wiring, 3-pin locking connectors. The same reliable electrical system as our flagship kits.
  • Fire-resistant connectors. Standard on every SV kit.
  • Spare parts included + stocked in-house.
  • 2-year warranty from a DFW business you can reach.

Specs

Panel count Diamond lattice with border frame
Assembled size 11'11" W × 8'0" H (143.17" × 95.79")
Brightness ~50,000 lumens · 6500K daylight white · CRI ≥90
Frames Aluminum, no sag, no warp
Wiring Copper, 3-pin locking connector
Ingress rating IP54
Dimming Full brightness, fixed (non-dimmable)
Install options Flush mount (included) or suspended (cable kit)
Warranty 2 years, spare parts included
Tolerance Assembled sizes are the finished footprint and are accurate to about 2 in. Tube and rail lengths are fixed, so the overall size lands on set increments rather than any dimension you name.

Power Requirements

Total draw ~440W (~4.0A at 110V)
Electrical Have a licensed electrician confirm the circuit you connect to can carry the load shown above.

What's in the Box

  • ~44 LED tubes + 10 border rails (pre-configured compact diamond lattice)
  • All connectors: 120° Y, 2-way, 3-way T, and corners
  • Power cables, zip ties, and mounting anchors
  • Spare parts kit

Add the Floating Look

Our Adjustable Coated Cables ($69.99) suspend the lattice off the ceiling for the look that gets photographed.

Compare SV Kits

Kit Panels Assembled size Lit area
5 Panel 5 5'6" × 7'11" 33 sq ft
6 Panel RGB 6 9'11" × 5'9" 42 sq ft
8 Panel 8 8'3" × 7'11" 52 sq ft
11 Panel 11 11'0" × 7'11" 72 sq ft
11 Panel w/Border 11 11'11" × 8'0" 72 sq ft
Diamond Compact Lattice 11'11" × 8'0" See listing
14 Panel w/Border 14 15'11" × 8'0" 91 sq ft
Diamond w/Border Lattice 15'11" × 8'0" See listing
18 Panel w/Border 18 15'11" × 11'11" 117 sq ft
Diamond XL Lattice 15'11" × 11'11" See listing
22 Panel w/Border 22 15'11" × 15'11" 144 sq ft
30 Panel Commercial 30 15'11" × 15'11" 196 sq ft
11 Panel RGB Framed 11 19'10" × 6'4" 77 sq ft

Sizes are finished footprints at the measured hex pitch. Lit area is the lit hexagon area inside that footprint.
