The Diamond With Border kit arranges the same premium tubes in a diamond lattice, then wraps the entire arrangement in a border trim that makes it look like something commissioned rather than ordered online. If the hex grid is the standard, the Diamond is the statement you make when you want the ceiling to be the first thing anyone talks about when they walk in.
Who This Is For
The Diamond kit attracts two types of customers: people who've seen the hex grid everywhere and want something distinct, and people who are designing a specific aesthetic where the geometric arrangement matters. Both get a kit held to the same standard as everything we sell, just with a layout that's harder to find anywhere else.
Specs
Panel count
Diamond lattice with border frame
Assembled size
15'11" W × 8'0" H (190.55" × 95.79")
Brightness
~63,500 lumens · 6500K daylight white · CRI ≥90
Frames
Aluminum, no sag, no warp
Wiring
Copper, 3-pin locking connector
Ingress rating
IP54
Dimming
Full brightness, fixed (non-dimmable)
Install options
Flush mount (included) or suspended (cable kit)
Warranty
2 years, spare parts included
Tolerance
Assembled sizes are the finished footprint and are accurate to about 2 in. Tube and rail lengths are fixed, so the overall size lands on set increments rather than any dimension you name.
Power Requirements
Total draw
~552W (~5.0A at 110V)
Electrical
Have a licensed electrician confirm the circuit you connect to can carry the load shown above.
What's in the Box
57 LED tubes + 12 border rails (pre-configured diamond lattice)
All connectors: 120° Y, 2-way, 3-way T, and corners
Power cables, zip ties, and mounting anchors
Spare parts kit
Add the Floating Look
Our Adjustable Coated Cables ($69.99) suspend the arrangement off the ceiling, 34 rust-resistant cables, each adjustable up to 36". The Diamond formation floating off the ceiling is something most people have never seen in person. It tends to get a reaction.
