Diamond LED Garage Lighting Kit - XL with Border (Non-Dimmable)

$849.99 USD

Sale Sold out

Shipping calculated at checkout.

Free shipping (lower 48) · Ships in 1–3 business days from DFW

Package Only Light Light + Installation Cable Kit

Measuring a space? Send us your dimensions — we'll design your hex layout free, with firm pricing in 24 hours →

The biggest statement in our lineup. The XL takes the diamond lattice to full commercial scale, nearly 16 feet wide and over 11 feet deep, wrapped in the border trim. Showrooms, detail shops, large garages, anywhere the ceiling IS the design. Nobody walks under this without looking up.

At This Scale, Build Quality Isn't Optional

Aluminum frames throughout, including the border. No sag, no warp, at any span.
Copper wiring, 3-pin locking connectors at every joint. More current capacity, no failure points.
Fire-resistant connectors, all of them.
Spare parts included + stocked in-house.
2-year warranty from a DFW business you can reach.

Specs

Panel count	Diamond lattice with border frame
Assembled size	15'11" W × 11'11" H (190.55" × 143.17")
Brightness	~86,000 lumens · 6500K daylight white · CRI ≥90
Frames	Aluminum, no sag, no warp
Wiring	Copper, 3-pin locking connector
Ingress rating	IP54
Dimming	Full brightness, fixed (non-dimmable)
Install options	Flush mount (included) or suspended (cable kit)
Warranty	2 years, spare parts included
Tolerance	Assembled sizes are the finished footprint and are accurate to about 2 in. Tube and rail lengths are fixed, so the overall size lands on set increments rather than any dimension you name.

Power Requirements

Total draw	~750W (~6.8A at 110V)
Power feeds	Ships pre-split across 2 power feeds so no single run is overloaded
Electrical	Have a licensed electrician confirm the circuit you connect to can carry the load shown above.

What's in the Box

~88 LED tubes + 14 border rails (pre-configured XL diamond lattice)
All connectors: 120° Y, 2-way, 3-way T, and corners
Power cables, zip ties, and mounting anchors
Spare parts kit

Suspended Installation

Add our Adjustable Coated Cables ($69.99), an XL diamond lattice floating off the ceiling is a genuine showpiece.

Compare SV Kits

Kit	Panels	Assembled size	Lit area
5 Panel	5	5'6" × 7'11"	33 sq ft
6 Panel RGB	6	9'11" × 5'9"	42 sq ft
8 Panel	8	8'3" × 7'11"	52 sq ft
11 Panel	11	11'0" × 7'11"	72 sq ft
11 Panel w/Border	11	11'11" × 8'0"	72 sq ft
Diamond Compact	Lattice	11'11" × 8'0"	See listing
14 Panel w/Border	14	15'11" × 8'0"	91 sq ft
Diamond w/Border	Lattice	15'11" × 8'0"	See listing
18 Panel w/Border	18	15'11" × 11'11"	117 sq ft
Diamond XL	Lattice	15'11" × 11'11"	See listing
22 Panel w/Border	22	15'11" × 15'11"	144 sq ft
30 Panel Commercial	30	15'11" × 15'11"	196 sq ft
11 Panel RGB Framed	11	19'10" × 6'4"	77 sq ft
